Is the value
=∞Ω?
GO TO STEP 13
 Ignition OFF
 Check the resistance between pin 14 and pin 16 of the DLC
Connector
 Examine the short circuit of
CAN LOW and battery positive
 Replace the wiring harness
 Check and confirm that ECU’s
are able to communicate with
the diagnostic tool
NOYES
Is the value
=∞Ω?
 Examine the short circuit of
CAN LOW AND CAN HIGH
wires
 Replace the wiring harness
 Check and confirm that ECU’s
are able to communicate with
the diagnostic tool
 Ignition OFF
 Check the resistance between pin 6 and pin 16 of the DLC Connector
 Examine the short circuit of
CAN HIGH and battery positive
 Replace the wiring harness
 Check and confirm that ECU’s
are able to communicate with
the diagnostic tool
NOYES
STEP 12 – CHECK SHORT TO BATTERY IN CAN LOW
STEP 13 – CHECK SHORT TO BATTERY IN CAN HIGH
DIAGNOSTIC MANUAL
SCORPIO
IMMOBILISER
MAN-00281
DEC 2014/Rev 1
54
