STEP A: CHECK THE FUSES
NOYES
GO TO STEP B
Replace the blown fuses.
Check the fuses F2, F4, F5, F53, F46
Are all the fuses
Good?
STEP B: CHECK BATTERY VOLTAGE IN ICU BATTERY SUPPLY WIRE
NOYES
GO TO STEP C
Check the wiring for any
discontinuity/short to ground.
Replace/repair.
Ignition off.
ICU connector (C251) removed.
Check for battery voltage at pin number 1 of
ICU connector (C251).
Is battery voltage
available?
DIAGNOSTIC MANUAL
SCORPIO
To Next Page
