Diagnostic Manual - SRS MAN-00081-29
Scorpio mHawk
January 2010/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be
modified as a result of changes introduced by the manufacturer in the production of the various component units and accessories from which the vehicles are
manufactured. The reproduction, translation, transmission, in part of or whole of the present document, are prohibited without the prior written consent of Mahindra &
Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authoirsed Service Centre of Mahindra & Mahindra Ltd., will amount
to unauthorized use and shall be liable for penalty/prosecution © 2010 Mahindra & Mahindra Ltd.
Using Airbag Diagnostic Tester
Connecting diagnostic tool to vehicle:
1. Connect the python hardware to the vehicle and the SMART tester.
2. Open the Python software by double clicking on the desktop.
3. Click auto detect in the window which opens and wait until Python
hardware is successfully detected.
4. Open the Airbag diagnostic software by double clicking on the
desktop.
5. Click on connect tab in the window which opens up as shown below to geet
connected to the ACU.
To Next Page
