BODY AIRBAG
SCORPIO
106
CHECK THE RHS PRETENSIONER LINE
IMPEDANCE IN DIAGNOSTIC TOOL
SRSL1
Select the LID3 tab in the diagnostic tool as shown above.
Read the RHS pretensioner resistance value
The specified range for RHS pretensioner is 2.0 to 3.0 ohms
Is the resistance within the specified range?
YES
No fault found.
No
GO to SRSL2
