BODY AIRBAG
SCORPIO
116
CHECK THE DRIVER AIRBAG LINE
IMPEDANCE IN DIAGNOSTIC TOOL
SRSI1
Select the LID3 tab in the diagnostic tool as shown above.
Read the DAB resistance value
The specified range for DAB is 2.5 to 3.5 ohms
Is the resistance within the specified range?
YES
No fault found.
No
GO to SRSI2
