BODY AIRBAG
SCORPIO
118
Restart the diagnostic tool and establish the communication with Airbag Module.
Select the LID3 tab in the diagnostic tool as shown above.
Read the DAB resistance value
The specified range for DAB is 2.5 to 3.5 ohms
Is the resistance within the specified range?
YES
Install the new DAB assembly (Refer the repair
manual for the installation procedure.)
No
If the resistance is more than 5.5 ohms GO to SRSI3
If the resistance is less that 1.9 ohms GO to SRSI4
