BODY AIRBAG
SCORPIO
127
CHECK THE PASSENGER AIRBAG LINE
IMPEDANCE IN DIAGNOSTIC TOOL
SRSJ1
Select the LID3 tab in the diagnostic tool as shown above.
Read the PAB resistance value
The specified range for PAB is 2.0 to 3.0 ohms
Is the resistance within the specified range?
YES
No fault found.
No
GO to SRSJ2
