BODY AIRBAG
SCORPIO
64
Floor Interconnector:
Harness side (Female Connector)
Vehicle Connector Pin Circuit
Scorpio_Airbag_LHD IC - Floor
1 RHS Pretensioner_Positive
2 RHS Pretensioner_Negative
Scorpio_Airbag_RHD IC - Floor
3 RHS Pretensioner_Positive
4 RHS Pretensioner_Negative
