BODY AIRBAG
SCORPIO
94
Floor Interconnector:
Harness side (Female Connector)
Vehicle Connector Pin Circuit
Scorpio_Airbag_LHD IC - Floor
3 LHS Pretensioner_Positive
4 LHS Pretensioner_Negative
Scorpio_Airbag_RHD IC - Floor
1 LHS Pretensioner_Positive
2 LHS Pretensioner_Negative
