Maidesite TH2 Pro Plus - Page 10

STEP 8: Connect Wires
STEP 7: Install the Control Panel
Connect the power cable, wires on the control panel,extension cable and the cable on lifting column to the corresponding ports.
P8
K.
K.
L.
L.
L.
Hardware List
5
ST5*0.8*16
Tapping Screw
×2
7
Screwdriver
Attention: Make sure control panel and adapter are
on the same side of table top.
Power Cable
Extension Cable×2
