Mainstays MS17-D4-1011-03 User Manual

11
Assembly Instructions for Table-top Display
12. Fasten the Top Shelf Frame (A) to the Lower Spine (D) by inserting one 2-1/2” Bolt (5) with
the Washers (6 and 7) through the drilled holes on the lower spine and securely screw into the
Flange Nut (8).
13. Plug Plastic End Cap (12) all the way onto the top of the Lower Spine (D).
2-1/2” Bolt
(1 used in this step)
⑤
Flange Nut
(1 used in this step)
⑧
Plastic End Cap
(1 used in this step)
⑫
Lock Washer
(1 used in this step)
⑥
Flat Washer
(1 used in this step)
⑦
A
A
D
6
7
5
8
A
D
12
D
D
