9
Assembly Instructions
9. Fasten the Top Frame Support (F) to the middle rail of the Top Shelf Frame (A) and the Spine
(D) with three 5/8” Bolts (2) and three Washers (6 and 7).
10. Stand the unit upright.
Lock Washer
(3 used in this step)
Flat Washer
(3 used in this step)
A
D
A
D
2
7
6
2
7
6
5/8” Bolt
(3 used in this step)
If you choose
the
Table
-
top configurat
ion
,
continue to the next step.
If mounting the TV to the Floating Swivel
Mount, skip ahead to PAGE 16.
