Mainstays STANTON - Page 11

REQUIRED
11
(G) Table Top x1
REQUIRED
(I) Table Leg x4
(CC) Bolt (40MM) x8
Assembly
3. ASSEMBLY TABLE
1. Insert Table Leg (I) into the joint on Table Top (G)
and tighten Bolts (GG).
2. Assemble Leg Connector Bracket (H) to legs using
Bolts 40MM (CC) ,Washers (FF) and Lock Nut (EE).
(GG) ST 4.8*13 x4
RATCHET
(H) Leg Connector
Bracket x1
(EE) Lock Nut x8
(FF) Washer x8
Ratchet Tool
Wrench
