Majestic Ruby - Upgrade Your Existing Wood Fireplace; Measure Existing Fireplace; Choose Your Insert; Choose Your Surround

FOUR EASY STEPS TO UPGRADE YOUR
EXISTING WOOD-BURNING FIREPLACE
1. Measure your existing fireplace 3. Choose your surround
2. Select your insert 4. Customize your insert
Distance from firebox to mantel
Back width
Depth from front
to back
Front width
Height from
hearth to top
of the opening
STEP 1 Measure Your Existing Fireplace –
The height, width and depth of the existing fireplace opening
is needed to ensure an appropriately sized insert is selected.
STEP 2 Choose Your Insert
• Consider how your insert will be used. Room size, heating needs and usage frequency all come into play.
MDVI30
• 30" viewing area
• Up to 30,500 BTUs
• Fan and remote
standard
MDVI35
• 35" viewing area
• Up to 35,000 BTUs
• Fan and remote
standard
STEP 3 Choose Your Surround – Surrounds fill the gap between the fireplace insert and existing fireplace
opening. Choose from three sizes and two finishes for a unique look.
SURROUND MDVI35 MDVI30
Small 42" x 29" 40" x 27"
Medium 44" x 32" 42" x 30"
Large 48" x 32" 44" x 32"
Small Surround
Medium Surround
Large Surround
Tavern Brown
STEP 4 Customize Your Insert – Select options to complete your look.
Contemporary Rectangular Door
(Clean Face)
Black
Bronze
Front Finishes
Cottage Red
Optional Interior Brick Panels
Termination Caps
A termination cap finishes your gas insert with
a clean, upscale look. These durable caps also
protect venting components and ensure safe
exhaust flow.
Round Termination Cap Square Termination Cap
(available in Black or Copper finish)
The RC200 remote and
wall dock come standard
with the Ruby insert. The
remote allows for adjustable
flame height, standing pilot
mode, child safety lock,
and memory settings.
Contemporary Rectangular Door
