Major tech MT Series - Technical Specifications

10
SPECIFICATIONS
Safety Standard :
IEC 61481
Electrical
MT6kV MT11kV MT22kV MT33kV MT44kV
Total Resistance 4.48MΩ 6.78MΩ 10.82MΩ 19.68MΩ 26.8MΩ
Response time <1Sec <1Sec <1Sec <1Sec <1Sec
Neon Threshold 1.2kV 1.2kV 1.2kV 1.2kV 1.2kV
Neon Lit Fully @ 1.5kV 1.5kV 1.5kV 1.5kV 1.5kV
Mechanical
MT6kV MT11k V MT22kV MT33kV MT44kV
Length of Handle 775mm 775mm 775mm 775mm 775mm
Length Front end 400mm 400mm 500mm 665mm 820mm
Total Length 1.175m 1.175m 1.275m 1.440m 1.595m
Total Weight 2.1kg 2.1kg 2.2kg 2.4kg 2.5kg
Handle Material Composite Material with Polyurethane
Front End Fiber Glass Wound Tubing
Vibration Resistance :
tested in accordance with IEC 60068-2-6
Drop Resistance :
tested in accordance with IEC 60068-2-31
Shock Resistance :
tested in accordance with IEC 60068-2-75
Climatic Resistance :
tested in accordance with IEC 60068-2-14
Deection :
the contact electrodes must not deect by more than
150mm when loaded at the electrode by 10N.
Connection Lead.Cord Strength :
each pole connection to
withstand 10000 swing with 10N Load applied and a
vertical pull with 200N applied.
Environmental :
Operating temperature: -25°C to +55°C
Operating Humidity: 20 to 96% RH.
