25
Propellers
2 CW Propellers
2 CCW Propellers
Parts:
• Make sure the battery is disconnected"
• Identify your propellers between CW (clockwise) and CCW
(counter clock wise):"
• Take a random propeller. Place it on a table, able to spin (1)
• Blow gently straight down above (2)
• If it rotates with the clock, its a CW propeller
• If it rotates against the clock, its a CCW propeller
• Place all four propeller on the correct motors
• The letters “CW” or “CCW” can also be read on the propeller
near the center top.
• If you need to remove a propeller, use some pliers and eject
the center of the prop. Do not bend the propeller blades.
