MakerBot mBot Ranger - Wiring of Land Raider

21
20
16
18
17
(1)
M4x8 (2)
1:1
Connect the left motor
and right motor to the
corresponding port of
Me Auriga.
1
2
3
(2)
Right motor (M1) Left motor (M2)
M1
M2
Wiring of Land Raider
Ultrasonic Sensor
Line Follower Sensor
180 Encoder Motor (M2)
180 Encoder Motor (M1)
Me Auriga
(2)
M1
M2
M1
M2
Please follow page 36 for controlling with App
