MAKINEX JHT-U-2 - PRODUCT DESCRIPTION AND SPECIFICATION; INSTRUCTIONS FOR USE; FITTING A JACKHAMMER

JHT-U-2 – User Manual REV0919 Page 5 of 15
PRODUCT DESCRIPTION AND SPECIFICATION
The Jackhammer Trolley enables your demolition hammer to lift most types of Ceramic
Floor Tiles, Vinyl and Cork with less effort.
With a wide range of angle, the Jackhammer Trolley adapts to any situation with a
maximum leverage.
Features
• Durable zinc coated frame
• Easy Angle adjustment
• Will suit most 16kg (35lbs) hammers
• Anti-vibration ergonomic design
• Large wheels
INSTRUCTIONS FOR USE
WARNING
Do not operate the Jackhammer without wearing the appropriate personal
protective equipment and assessing the surrounding area for hazards.
FITTING A JACKHAMMER
Tools Required
▪ 17mm spanner
▪ 2mm allen key
▪ 19mm spanner
▪ Pliers
HEIGHT WHEN RAISED
1100mm/43.3’’
HEIGHT WHEN LOWERED
600mm/23.6’’
OVERALL WIDTH
510mm/20’’
OVERALL LENGTH
1100mm/43.3’’
ANGLE OF ADJUSTMENT
73° (93° closed, 20° open)
WEIGHT (WITHOUT JACKHAMMER)
28kg/62lb
