7 ENGLISH
Graduation 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Machine screw M4 M5 M6
Wood
screw
Soft wood
(e.g. pine)
– ɸ3.5 x 22 ɸ4.1x 38 –
Hard wood
(e.g. lauan)
– ɸ3.5 x 22 ɸ4.1x 38 –
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
Installing or removing driver bit/
drill bit
For Model DF332D (optional accessory)
3
2
1
►1. Sleeve 2. Close 3. Open
Turnthesleevecounterclockwisetoopenthechuck
jaws.Placethedriverbit/drillbitinthechuckasfar
asitwillgo.Turnthesleeveclockwisetotightenthe
chuck.Toremovethedriverbit/drillbit,turnthesleeve
counterclockwise.
Installing or removing driver bit/
socket bit
For Model DF032D (optional accessory)
Useonlydriverbit/socketbitthathasinsertingportion
showninthegure.Donotuseanyotherdriverbit/
socket bit.
For tool with shallow driver bit hole
A=12mm
B=9mm
Useonlythesetypeofdriver
bit. Follow the procedure
1. (Note) Bit-piece is not
necessary.
For tool with deep driver bit hole
A=17mm
B=14mm
Toinstallthesetypesofdriver
bits, follow the procedure 1.
A=12mm
B=9mm
Toinstallthesetypesofdriver
bits, follow the procedure 2.
(Note) Bit-piece is necessary
for installing the bit.
1. Toinstallthedriverbit,pullthesleeveinthedirec-
tion of the arrow and insert the driver bit into the
sleeve as far as it will go.
Thenreleasethesleevetosecurethedriverbit.
2
1
►1. Driver bit 2. Sleeve
2. Toinstallthedriverbit,pullthesleeveinthedirec-
tion of the arrow and insert the bit-piece and driver
bitintothesleeveasfarasitwillgo.Thebit-piece
should be inserted into the sleeve with its pointed
endfacingin.Thenreleasethesleevetosecure
the driver bit.
1 2 3
►1. Driver bit 2. Bit-piece 3. Sleeve
