6
English
Icon Description Purpose
Reector nozzle Soldering pipes
Reduction nozzle Welding, sleeve shrinking (heat concentrated over small area )
Wide-slot nozzle Drying, thawing (heat spread over wider area )
Overlap welding nozzle Welding
Solder sleeves reector Soldering
Welding nozzle Welding
Pressure roller Press the surface of working piece
Scraper Stripping paint and varnish
Q Make sure that the tool is switched off and the nozzle has cooled down.
Q Falling down nozzle may ignite objects on the oor. Nozzles must be mounted rmly and
secure on the unit.
Q Touching a hot nozzle can lead to serious burn.Before attaching or replacing a nozzle,
allow the unit to cool down completely or use a suitable tool.
Q A hot nozzle can set a surface on re. Place down hot nozzles only on re-proof surfaces.
Q An incorrect or defective nozzle can lead to heat accumulation and damage the unit. Use
only original nozzles according to the table that are suitable for your unit.
