7 ENGLISH
•
The maximum bevel during traction is at least 30°.
• Do not apply vehicles for traction.
•
explosive or erosive service.
• To prevent unintentional start-up;
— do not carry the compressor over a long
distance;
— do not carry with the compressor with its
— do not bring into a potentially dangerous
situations, such as in a vehicle or on a
Electrical safety
1. Avoid dangerous environment. Don't use the
air compressor in damp or wet locations or
expose it to rain. Water entering the air compres-
sor will increase the risk of electric shock.
2. Prevent unintentional starting. Ensure the ON/
unplug when picking up or carrying the air
compressor. Carrying the air compressor with
-
pressor that have the switch on invites accidents.
3.
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
4. Do not modify or attempt to repair the air com-
pressor except as indicated in the instructions
for use and care.
INTRODUCTION
General information
This air compressor is equipped with an Oil-Less pump
designed for durability and no maintenance.
The compressor can be used for properly rated pneu-
matic nailers and staplers. An air pressure regulator is
supplied for these applications.
Intended use
nailing and stapling applications.
WARNING: Never use compressor for appli-
cations other than to operate a properly rated
nailer or stapler. Use of the compressor for other
applications could result in property damage and
Separate air transformers which combine the
functions of air regulation and/or moisture and dirt
removal should be used where applicable.
WARNING: Use the pressure gauge only for a
reference. Check the air pressure using calibrated
objects.
Parts description
Fig.1
1 2 Check valve 3 Safety valve 4 Air compressor pump
5 Regulator 6 Tank pressure gauge 7 Outlet pressure gauge 8 Quick coupler
9 Carrying handle 10 Air tank 11 Drain valve 12 Pressure switch
13 Power cord 14 ON/AUTO-OFF switch 15 Pressure switch unload-
ing valve
16 Thermal circuit breaker
17 Reset button - - - - - -
CAUTION: Always use accessories and attachments recommended for use with Makita product. Not
doing so may cause personal injury. Accessories and attachments must be used for its original purpose. If
you need any assistance, ask your local Makita Service Center.
Glossary
MPa (megapascal): Metric pressure measurement. 1
megapascal equals to 10 bar.
Cut-in pressure:-
sure drops as you continue to use your accessory or
air tool. When the tank pressure drops to a certain level
the motor will restart automatically re-started is called
“cut-in pressure”.
Cut-out pressure: When you turn on your air compres-
sor, it begins to run, air pressure in the air tank begins
to build. It builds to a certain pressure before the motor
pressure higher than its design rating. The pressure at
On-receipt inspection
and checked before shipment. With improper handling,
damage may result in transit and cause problems with
compressor operation.
Immediately upon arrival, check equipment for both
concealed and visible damages to avoid expenses
being incurred to correct such problems. This should be
done regardless of any visible signs of damage to the
shipping container. If this product was shipped directly
to you, report any damages to the carrier and arrange
for inspection of goods immediately.
