FRANÇAIS
Description des pièces
1. Filtre à air (admission d’air)
2. Clapet antiretour
3. Soupape de sécurité
4. Pompe de compression d’air
5. Régulateur
6. Manomètre de réservoir
7. Manomètre de sortie
8. Raccord rapide
9. Réservoir d’air
10. Robinet de vidange
11. Manostat
12. Cordon d’alimentation
13. Interrupteur MARCHE/AUTOMATIQUE - ARRÊT
14. Valve de décompression de manostat
Remarque :
La forme du robinet de vidange des modèles MAC100Q et MAC210Q n’est pas la même.
2
1
3
6
5
7
8
9 10
11
1312
14
4
MAC100Q, MAC210Q
2
1
3
6
5
7
9 10
11
1312
14
8
4
MAC320Q
