10
Chamfering
To make a chamfering cut as shown in the figure, align the “V” groove in the
front base with the edge of the workpiece and plane it.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and unplugged before
attempting to perform inspection or maintenance.
Sharpening the planer blades (optional accessory)
Always keep your blades sharp for the best performance possible. Use the
sharpening holder (optional accessory) to remove nicks and produce a fine
edge.
First, loosen the two wing nuts on the holder and insert the blades (A) and (B),
so that they contact the sides (C) and (D). Then tighten the wing nuts.
1. “V” groove
003634
1
004847
1. Sharpening holder
1
002588
1. Wing nut
2. Blade (A)
3. Blade (B)
4. Side (D)
5. Side (C)
1
2
3
5
4
004952
