Reinforcement Installation
X-Factor
Insert the last blocks (C)
underneath the footwell,
between the scupper holes.
Make sure each block (C) is
tightly positioned as shown in
this picture.
Mount these blocks (C) onto the
outer grooves. Push each block
securely into place.
www.malibukayaks.com support@malibukayaks.com 1-877-952-9257
Malibu Kayaks LLC. all rights reserved.
7 8
2
C
C
C
C
C
C
C
C
9
2
www.malibukayaks.com support@malibukayaks.com 1-877-952-9257
Malibu Kayaks LLC. all rights reserved.
www.malibukayaks.com support@malibukayaks.com 1-877-952-9257
Malibu Kayaks LLC. all rights reserved.
Reinforcement Foam Blocks Template
X-Factor
Use the template as a reference to measure
and cut the foam blocks.
