AUTOMATIC TEST OPTION
Once the unit is powered up it will automatically initiate a self test. The self test will check
the function of the luminaire and indicate its status as follows:
• Every 4 seconds: Checks for battery disconnection, charge board fault, lamp failure
and transformer failure.
• Every month: Performs a 3 minute duration test.
• Every year: Performs a 3 hour duration test.
All test functions are factory preset and do not need field adjustment.
Dual Colour Indicator LED Status Meanings:
Green Solid on Ready/Normal operation
Flashing Testing
Red Solid on Requires service
•
One flash, 4 second pause Battery not connected
••
Two flashes, 4 second pause Battery short or low battery voltage
•••
Three flashes, 4 second pause Charge board fault
••••
Four flashes, 4 second pause Transformer fault
•••••
Five flashes, 4 second pause LED lamp fault
NOTE: After repairing a service fault, press and hold the test button for 2 seconds to reset
the flashing indicator light to green.
MANUAL TESTING
Press test button once 30 seconds duration test
Press test button twice (within 2 seconds) 3 minutes duration test
Press test button 3 times (within 2 seconds) 30 minutes duration test
Press test button 4 times (within 2 seconds) 3 hours duration test
