1 Player section
SD/MMC Connection for SD cards
Connection for USB storage
media (USB sticks, portable USB
hard disks, MP3 players)
MODE Press repeatedly for mode
selection (SD/USB/BT/LINE-in/
AUX/radio)
Play/Pause
REPEAT Press repeatedly for repeat modes
Back/Forward
2 VOLUME Volume control
3 EQ Bass and treble adjustment
4 MIX OUT Output (RCA) of the total (for example for
recording purposes)
5 LINE INPUT Audio input (RCA)
6 POWER ON/OFF Power switch
7 Fuse
8 DC-IN Power supply connection
9 Status LEDs POWER = operation LED; CHARGE = charging
LED
10 ANT Connection for microphone antenna
11 AUX-IN Audio input (3.5 mm jack) for connecting
external devices (MP3 player, smartphone,
laptop)
12 MIC1 / MIC2 Microphone connections (6.3 mm jack)
13 VCA ON/OFF Turning VCA on/off
14 MIC VOL Microphone volume
15 WIRELESS Wireless microphone volume
16 ECHO Control for the built-in echo effect
To Next Page
