Mammoth 98874 - Connecting Extension Arms and Coil Springs

13
STEP 9
EA
EC
EJ
Required For This Page:
15/16” Wrench
(Not
actual
length)
(2)
(1)
(1)
11 1/4”
SB
SG
HH18200
SE
SD
a. Tighten the Hex Nut (SA) onto the Hex Bolt (SB) until it is
about one inch (1”) from the top of Spacer (SE).
b. Apply a small amount of Dark Lithium Grease to the rounded
side of the D-Pin (SG) for each bolt.
c. Slide the Bolt through each Spring bracket on the back of the
Pole, making sure the curved side of the D-Pin rests inside
the curve of the bracket.
STEP 10
SA
(Not actual size)
a. While at least one adult holds the Pole up, position the
Lower Extension Arm (AT) next to the Pole, lining up
the holes in the Arm with the holes in the Pole.
Note: e Arms must face the right direction as shown,
with the Cams facing the top of the Pole.
b. Apply a small amount of Dark Lithium Grease (AE) to
a 5/8” x 11 1/4” Hex Bolt (EJ).
c. Slide the greased Bolt (EJ) through a 5/8” O-ring (ZA),
a 5/8” Washer (EA), the Extension Arms, the Pole, the
other side of the Extension Arm, another 5/8” Flat
Washer (EA) and another 5/8” O-ring. Secure the Bolt
with a 5/8” Nylock Jam Nut (EC). Tighten the Nut
securely, but make sure the Extension Arm and the
Washers can rotate freely.
AT
STEP 8
HH18600
ZA
(2)
9/16” Wrench
EJ
EA
ZA
EA
ZA
EC
SB
a. S c r ew t h e Co i l
Springs (AC) onto
the 3/8” x 8” Hex
Bolts (SB). Tighten
the Coil Spring only
ve turns onto the
Bolt at this time.
SE
SG
SD
SB
SA
1”
