12
1. Controls and Connectors
No. Description
1 Power ON/OFF Switch & volume control
2 LCD Display
3 Squelch control
4 Function selector by short press
5 Microphone connector
6 AM/FM (Menu button)
7 SCAN, MSCAN (Memory Scan)
8
VOX on/off, EMG (Emergency channel 9),
SHIFT (channel 19)
9 MEM (Memory recall), MSAVE (Memory save)
10 ASQ (Automatic Squelch), CTCSS
11 Rotary channel control
12 Antenna Connection with PL 259 coaxial Connector
13 12/24V DC power input
14 External Speaker Socket (for 3.5 mm mono plug)
Microphone
No. Description
15 Push-to-talk Switch (PTT)
16 DOWN key
17 ASQ on/off
18 UP key
