PAGE 28
OWNER’S/OPERATOR’S MANUAL – 6150 PART NUMBER 14569
SPECIFICATIONS
Dimensions
Overall Length ----------------------------------------------- 91.0 in. (2311mm)
Overall Width ------------------------------------------------ 47.3 in. (1200mm)
Overall Height ----------------------------------------------- 55.4 in. (1406mm)
Wheelbase ---------------------------------------------------- 59.0 in. (1500mm)
Front Track (C/L of Tire) ------------------------------------ 41.0 in. (1040mm)
Rear Track (C/L of Tire) ------------------------------------- 36.3 in. ( 920mm)
Ground Clearance ---------------------------------------------- 6.7 in. ( 170mm)
Engine
Type --------------------------------- Single Cylinder Oil & Air cooled 4-Stroke
Engine capacity ---------------------------------------------------------- 150cc
Bore / Stroke -------------------------------------------------- 57.4mm x 57.8mm
Displacement ---------------------------------------------------------- 149.6 cm
3
Corrected compression ratio ---------------------------------------------- 9.2:1
Carburetor ----------------------------------------------------------- KF, CB24J
Output Power -------------------------------------------------- 9.9 hp @ 7500rpm
Maximum Torque --------------------------------------------- 13 ft-lbs @ 5500rpm
Starting -------------------------------------------------------- Keyed Electric
Ignition ------------------------------------------------------------------- CDI
Lubrication ------------------------------------------ Force & Splash SAE-10W/40
Transmission ------------------------------- CVT automatic with Neutral and Reverse
Spark plug --------------------------------------------------------- C7HSA (NGK)
Plug gap ------------------------------------------------------------- 0.6-0.7mm
Fuel Type --------------------------------------- Mid-Grade Unleaded (89 Octane)
Capacities
Maximum load (Driver, Passenger, & Gear) -------------------------------- 400lbs
Fuel tank ------------------------------------------------------------- 2.64 Gal
Engine oil --------------------------------------------------------------- 30 Oz
Climbing Angle --------------------------------------------------------- 20
o
- 25
o
Battery --------------------------------------------------------------- 12V 10Ah
Fuse ------------------------------------------------------------------------ 15A
Top speed (20mph Speed Reduction Kit Available) --------------------------- 35 – 39mph
Miscellaneous
Brakes (Rear) --------------------------------------------------- Hydraulic Disc
Front tire ----------------------------------------------------- 17 x 7-8 @ 15psi
Rear tire ---------------------------------------------------- 18 x 9.5-8 @ 10psi
Front Suspension ---------------------------------------- Independent Dual A-Arm
Rear Suspension ------------------------------- Swing Arm/Double Oil Damped Shock
Restraint System ------------------------------------ 3-Point Retractor Style Belt
Final Drive Chain ----------------------------------------- KMC #50 – 5/8” Pitch
Net Weight ------------------------------------------------------------- 436 lbs
