Ref. # Part # Description Qty.
1 14254 Head, Cylinder - 150cc 1
2 50304 Plug, Spark - NGK C7HSA 1
3 14255 Gasket, Cylinder Head - 150cc 1
4 14256 Gasket, Carb Insulator - 150cc 1
5 14257 Insulator, Carb - 150cc 1
6 14258 Manifold, Intake - 150cc 1
7 14259 Clamp, Carb Hose - 150cc 1
8 14260 Gasket, Valve Cover - 150cc 1
9 14261 O-Ring, M27x2 Rubber 1
10 14262 Tube, Breather - 150cc 1
11 14263 Stud, M6 x 1.00 x 18 2
12 14264 Stud, M6 x 1.00 x 50 2
13 50003 Bolt, M6 x 1.00 x 25 FHCS 4
14 50024 Nut, M6 x 1.00 Hex Flange 2
15 14265 Cover, Valve - 150cc 1
16 14266 Pin, M10 x 16 Dowel 2
17 50087 Bolt, M6 x 1.00 x 100 FHCS 2
18 14267 Valve, Intake - 150cc 1
19 14268 Seal, Valve Stem - 150cc 2
20 14269 Seat, Valve Spring Outer - 150cc 2
21 14270 Spring, Outer and Inner Valve - 150cc 2
22 14271 Retainer, Valve Spring - 150cc 2
23 14272 Keeper, Valve Spring - 150cc 4
24 14273 Valve, Exhaust - 150cc 1
Section 1 - Cylinder Head Assembly
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
