M&B Engineering WB 255 - Page 62

62
solutions creator
C O D . 300210 R E v . 0
FUSE F1
500mA T
FUSE F2
500mA T
JP6
JP12
MICRO
CARTER
JP5
R1
R2
FUSE F3
2.5A
STEP-UP TRANSFORMER
115 / 230
SWITCH
MAIN
JP9
M
JP11
JP14
CAPACITOR
16UF 400VAC
JP10
JP3
1
2
3
BLUE
YELLOW-GREEN
BROWN
4
3
6
N
M1 M3 C2 C1 M2
L L 1 2 3
PROGRAMMING
CONNECTOR
WB255
RED
RED
RED
Power supply 115 / 230 VAC
RED
BLACK
PICK-UP
PICK-UP
INTERNAL
EXTERNAL
YELLOW-GREEN
BOARD
DISTANCE
DIAMETER
BLUE
BLUE
PLUG type C13
(VDE)
BROWN
BROWN
OPTO-ELECTRONIC
BOARD
BLUE
GRAY
GRAY
ORANGE
ORANGE
JP1
FLAT 10 POLES
L1
L2
T1
Power supply 230VAC: L1 connected to L2 and T1 not mounted
Power supply 115VAC: L1 and L2 connected to T1
FLAT 10 POLES
BOARD
