DIMENSIONS PRESSURE
STANDARD
17,5LR24 XM27 TL 145A8 3,5 Bar
51 psi
2 - 8
MLT 629 Turbo Série A
CHARACTERISTICS
FRONT AND REAR TIRES
OPTION
15,5/80-24 SGI TL 12PR 4 Bar
GOODYEAR
58 psi
460/70 R24 IT520 TL 150A8 3,3 Bar
GOODYEAR
48 psi
445/70R24 IT510 151G 4,1 Bar
GOODYEAR
60 psi
OPTION
14,9x24 T35 Stabilarge 18PR 3,4 Bar
DUNLOP
49 psi
400/70-20 T37 150B TL 14PR 3,25 Bar
DUNLOP
47 psi
440/70-24 T37 147B TL 2,8 Bar
DUNLOP
41 psi
OPTION
15,5R25 XHA 2,75 Bar
MICHELIN
40 psi
1200R20 X MINE D2 5 Bar
MICHELIN
73 psi
OPTION
500-60/22,5 TWIN 404 12PR 2,5 Bar
TRELLEBORG
36 psi
HYDRAULIC CIRCUIT
- Type of pump
. Capacity
- Lifting, tilting, telescoping, attachment circuit
. Max. rating capacity unladen
. Pressure
- Steering circuit
. Max. rating capacity unladen
. Pressure
- Braking circuit
. Max. rating capacity unladen
. Pressure
- Filtration
. Return
. Suction
Gear pump with flow divider
43,77 cm
3
(17.23 cu.in.)
105 L/mn (27.75 gal/mn)
250 Bar (3625 psi)
105 L/mn (27.75 gal/mn)
140 Bar (2030 psi)
105 L/mn (27.75 gal/mn)
40 Bar (580 psi)
20 Micron
125 Micron
When changing or replacing the tires and wheels; use
only the manufacturer’s approved components as
installed at the factory. Any substitutes or
modifications must first be approved by the
manufacturer.
IMPORTANT
