Manitou A Series Operator's Manual

2 - 12
HYDRAULIC CIRCUIT
- Type of pump
. Capacity
- Lifting, tilting, telescoping, attachment circuit
. Max. rating capacity unladen
. Pressure
- Steering circuit
. Max. rating capacity unladen
. Pressure
- Braking circuit
. Max. rating capacity unladen
. Pressure
- Filtration
. Return
. Suction
Variable displacement piston pump
60 cm
3
(23.6 cu in)
144 L/mn (38 gal/mn)
270 Bar (3,915 psi)
144 L/mn (38 gal/mn)
140 Bar (2,030 psi)
144 L/mn (38 gal/mn)
40 Bar (580 psi)
20 Micron
125 Micron
MLT 633 LS Turbo Série A
CHARACTERISTICS
FRONT AND REAR TIRES
OPTION
DIMENSIONS PRESSURE
15,5/80-24 SGI TL 12PR 4 Bar
GOODYEAR 58 psi
460/70 R24 IT520 TL 150A8 3,3 Bar
GOODYEAR 48 psi
445/70R24 IT510 151G 4,1 Bar
GOODYEAR 60 psi
OPTION
14,9x24 T35 Stabilarge 18PR 3,4 Bar
DUNLOP 49 psi
400/70-20 T37 150B TL 14PR 3,25 Bar
DUNLOP 47 psi
405/70R24 EM SPT9 TL 158A2 5 Bar
DUNLOP 73 psi
440/70-24 T37 147B TL 2,8 Bar
DUNLOP 41 psi
STANDARD
17,5LR24 XM27 TL 145A8 3,5 Bar
MICHELIN 51 psi
OPTION
15,5R25 XHA 2,75 Bar
MICHELIN 40 psi
1200R20 X MINE D2 5 Bar
MICHELIN 73 psi
OPTION
500-60/22,5 TWIN 404 12PR 2,5 Bar
TRELLEBORG 36 psi
When changing or replacing the tires and wheels; use
only the manufacturer’s approved components as
installed at the factory. Any substitutes or
modifications must first be approved by the
manufacturer.
IMPORTANT
FORKLIFT SAFETY
CONTENTS
