Manitou A Series - Page 59

2 - 19
A
B
C
C1
D
D1
D2
E
F
F1
G
G1
G2
I
J
K
L
N
O
P2
P3
R
S
T
U1
U2
V
V1
V2
W
Y
Z
MLT 730
-120 LS Turbo Série A
1200 mm (47.24 in)
2560 mm (100.78 in)
1392 mm (54.80 in)
1297 mm (51.06 in)
4712 mm (185.51 in)
4617 mm (181.77 in)
3920 mm (154.33 in)
5912 mm (232.75 in)
1850 mm (72.83 in)
1850 mm (72.83 in)
455 mm (17.91 in)
440 mm (17.32 in)
440 mm (17.32 in)
760 mm (29.92 in)
865 mm (34.05 in)
1260 mm (49.60 in)
45 mm (1.77 in)
1720 mm (67.71 in)
125 mm (4.92 in)
47,5 °
53 °
3475 mm (136.81 in)
7572 mm (165.94 in)
4215 mm (165.94 in)
2300 mm (90.55 in)
2490 mm (98.03 in)
4825 mm (189.96 in)
1205 mm (47.44 in)
3700 mm (145.66 in)
2305 mm (90.74 in)
12,3 °
133,8 °
