2 - 8
PERKINS 1004.42 (AR 81026 or AR 81334)
PERKINS 1004.40T (AK 80920 or AK 81335)
PERKINS 1004.40TW (AM 80922 or AM 81337)
PERKINS 1004.40T (AK 80920 or AK 81335)
PERKINS 1004.40TW (AM 80922 or AM 81337)
PERKINS 1004.40T (AK 80920 or AK 81335)
PERKINS 1004.42 (AR 81026 or AR 81334)
PERKINS 1004.40T (AK 80920 or AK 81298 or AK 81336)
1004.42 AR 81026 1004.40T AK 80920 1004.40T AK 81298 1004.40TW AM 80922
1004.42 AR 81334 1004.40T AK 81335 1004.40T AK 81336 1004.40TW AM 81337
4 in line 4 in line 4 in line 4 in line
4444
Natural Compressed turbo Compressed turbo Compressed turbo
Direct Direct Direct Direct
1.3.4.2. 1.3.4.2. 1.3.4.2. 1.3.4.2.
0,20 mm 0,20 mm 0,20 mm 0,20 mm
0,45 mm 0,45 mm 0,45 mm 0,45 mm
4233 cm
3
3990 cm
3
3990 cm
3
3990 cm
3
103 mm 100 mm 100 mm 100 mm
127 mm 127 mm 127 mm 127 mm
18.5 / 1 17.25 / 1 17.25 / 1 17.25 / 1
2200 rpm 2200 rpm 2200 rpm 2200 rpm
930 rpm 930 rpm 930 rpm 930 rpm
2350 rpm 2400 rpm 2400 rpm 2380 rpm
80 cv / 60 kw 104 cv / 76,5 kw 100 cv / 74,6 kw 121 cv / 90,5 kw
290 Nm at 1400 rpm 394 Nm at 1400 rpm 402,6 Nm at 1400 rpm 434 Nm at 1500 rpm
Dry 3 µ Dry 3 µ Dry 3 µ Dry 3 µ
By water
Puller
10
508 mm
77 °C to 85 °C
92 °C to 98 °C
TURNER POWERTRAIN SYSTEMS
SACHS
4
4
Electro-hydraulic
+20
- 0
+20
- 0
+20
- 0
+20
- 0
ENGINE
- Type
MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
MT 732/932 Série A
MT 732 Turbo Série A
- Number of cylinders
- Number of strokes
- Suction
- Injection system
- Ignition sequence
- Clearance of rocker valve (Cold)
. Inlet
. Exhaust
- Capacity
- Bore
- Stroke
- Compression ratio
- Nominal rating loaded
- Rating slow unladen
- Max. rating unladen
- Power ISO/TR 14396
- Maximum torque ISO/TR 14396
- Air cleaner
COOLING CIRCUIT
- Type
- Fan
. Number of blades
. Diameter
- Thermostat
. Start opening
. Full opening
TRANSMISSION
MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MT 732/932 Série A
MT 732 Turbo Série A
- Type
- Torque converter
- Gear box
. Number of forward speeds
. Number of reverse speeds
- Gear reverser
CHARACTERISTICS

Manitou A Series Specifications

General

Brand	Manitou
Model	A Series
Category	Front End Loaders
Language	English
