Manitou A Series User Manual

2 - 10
FRONT AND REAR TYRES
HYDRAULIC CIRCUIT
- Type of pump
. Capacity
- Lifting, tilting, telescoping, attachment circuit
. Max. rating capacity unladen
. Pressure
- Steering circuit
. Max. rating capacity unladen
. Pressure
- Braking circuit
. Max. rating capacity unladen
. Pressure
- Filtration
. Return
. Suction
Gear pump with flow divider
43,77 cm3
105 L/mn
250 Bar
105 L/mn
140 Bar
105 L/mn
40 Bar
20 µ
(Up to machine Nr : 166043)
15 µ (From machine Nr : 166044)
125 µ
MLT 629 Série A
CHARACTERISTICS
STANDARD
DIMENSIONS PRESSURE TYRE LOAD PRESSURE ON THE CONTACT SURFACE AREA OF THE CONTACT SURFACE
HARD GROUND LIGHT GROUND HARD GROUND LIGHT GROUND
15,5/80-24 SGI TL 12PR 4 Bar 1600 kg 7,6 kg/cm2 2,1 kg/cm2 210 cm2 770 cm2
GOODYEAR 4050 kg 11,4 kg/cm2 3,1 kg/cm2 356 cm2 1320 cm2
1600 kg 7,6 kg/cm2 2,1 kg/cm2 210 cm2 770 cm2
600 kg 7,5 kg/cm2 2,1 kg/cm2 80 cm2 290 cm2
OPTION
460/70 R24 IT520 TL 150A8 3,3 Bar 1600 kg 8,6 kg/cm2 2,3 kg/cm2 185 cm2 710 cm2
GOODYEAR 4050 kg 11,9 kg/cm2 3,1 kg/cm2 341 cm2 1310 cm2
1600 kg 8,6 kg/cm2 2,3 kg/cm2 185 cm2 710 cm2
600 kg 7,9 kg/cm2 2,1 kg/cm2 76 cm2 290 cm2
445/70R24 IT510 151G 4,1 Bar 1600 kg 8,4 kg/cm2 2,8 kg/cm2 190 cm2 570 cm2
GOODYEAR 4050 kg 9,8 kg/cm2 3,3 kg/cm2 412 cm2 1239 cm2
1600 kg 8,4 kg/cm2 2,8 kg/cm2 190 cm2 570 cm2
600 kg 6,5 kg/cm2 2,2 kg/cm2 93 cm2 275 cm2
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
14,9x24 T35 Stabilarge 18PR 3,4 Bar 1600 kg 5,7 kg/cm2 2 kg/cm2 280 cm2 810 cm2
DUNLOP 4050 kg 8,9 kg/cm2 3 kg/cm2 455 cm2 1360 cm2
1600 kg 5,7 kg/cm2 2 kg/cm2 280 cm2 810 cm2
600 kg 4,4 kg/cm2 1,5 kg/cm2 138 cm2 400 cm2
400/70-20 T37 150B TL 14PR 3,25 Bar 1600 kg 7,3 kg/cm2 2,3 kg/cm2 220 cm2 690 cm2
DUNLOP 4050 kg 10,1 kg/cm2 3,2 kg/cm2 400 cm2 1270 cm2
1600 kg 7,3 kg/cm2 2,3 kg/cm2 220 cm2 690 cm2
600 kg 5,6 kg/cm2 1,8 kg/cm2 107 cm2 335 cm2
440/70-24 T37 147B TL 2,8 Bar 1600 kg 6,3 kg/cm2 1,8 kg/cm2 255 cm2 890 cm2
DUNLOP 4050 kg 9 kg/cm2 2,6 kg/cm2 450 cm2 1550 cm2
1600 kg 6,3 kg/cm2 1,8 kg/cm2 255 cm2 890 cm2
600 kg 4,7 kg/cm2 1,3 kg/cm2 128 cm2 445 cm2
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
17,5LR24 XM27 TL 145A8 3,5 Bar 1600 kg 1,6 kg/cm2 kg/cm2 1020 cm2 cm2
MICHELIN 4050 kg 3,1 kg/cm2 kg/cm2 1310 cm2 cm2
1600 kg 1,6 kg/cm2 kg/cm2 1020 cm2 cm2
600 kg 0,7 kg/cm2 kg/cm2 900 cm2 cm2
15,5R25 XHA 2,75 Bar 1600 kg 2,1 kg/cm2 1 kg/cm2 760 cm2 1630 cm2
MICHELIN 4050 kg 2,5 kg/cm2 1,1 kg/cm2 1600 cm2 3533 cm2
1600 kg 2,1 kg/cm2 1 kg/cm2 760 cm2 1630 cm2
600 kg 1,4 kg/cm2 0,7 kg/cm2 420 cm2 905 cm2
1200R20 X MINE D2 5 Bar 1600 kg 3,1 kg/cm2 kg/cm2 510 cm2 cm2
MICHELIN 4050 kg 5,4 kg/cm2 kg/cm2 750 cm2 cm2
1600 kg 3,1 kg/cm2 kg/cm2 510 cm2 cm2
600 kg 1,7 kg/cm2 kg/cm2 360 cm2 cm2
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
500/65 R 24 TR 3,2 Bar 1600 kg 2,1 kg/cm2 0,9 kg/cm2 780 cm2 1880 cm2
FOREST MULTIPLUS TL 4050 kg 2,7 kg/cm2 1,5 kg/cm2 1500 cm2 2650 cm2
NOKIAN 1600 kg 2,1 kg/cm2 0,9 kg/cm2 780 cm2 1880 cm2
600 kg 1,2 kg/cm2 0,4 kg/cm2 490 cm2 1400 cm2
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
500-60/22,5 TWIN 404 12PR 2,5 Bar 1600 kg 2,7 kg/cm2 1,4 kg/cm2 593 cm2 1143 cm2
TRELLEBORG 4050 kg 2,7 kg/cm2 1,4 kg/cm2 1500 cm2 2893 cm2
1600 kg 2,7 kg/cm2 1,4 kg/cm2 593 cm2 1143 cm2
600 kg 2,7 kg/cm2 1,4 kg/cm2 222 cm2 429 cm2
Front unladen
Front laden
Rear unladen
Rear laden
