Manitou A Series User Manual

2 - 60
CRAB
STEER
HIGHWAY
TRAFFIC
4 WHEEL
STEER
B
A
D
C
20 - STEERING SELECTION LEVER
Before selecting one of the three possible steering positions, bring the 4 wheels into
alignment, i.e., in the straight ahead position.
(See chapter : 6 - SWITCH AND LAMPS FOR ALIGNMENT OF THE WHEELS in
paragraph : 2 - DESCRIPTION).
A - Front wheel steer (Highway traffic).
B - Front and rear wheels steer in opposite direction (4 wheel steer).
C - Front and rear wheels steer in the same direction (Crab steer).
21 - HYDRAULIC CONTROLS AND TRANSMISSION CUT
-OFF
Do not attempt to alter the hydraulic system pressure by interfering with the pressure
regulating valve. In the event of suspected malfunction, contact your dealer. ANY
ALTERATION MAY RENDER THE WARRANTY NULL AND VOID.
Use the hydraulic controls carefully without jerking, to avoid accidents caused by
shaking the lift truck.
MLT 629/730 Série A
MT 732/932 Série A
MT 732 Turbo Série A
LEVER A : Controls the lifting of the load and the tilt of the carriage.
- The lever backwards when lifting.
- The lever forwards when lowering.
- The lever to the left for reverse tilt.
- The lever to the right for forward tilt.
LEVER B : Controls the telescoping.
- The lever backwards for the retraction.
- The lever forwards for the extension.
NOTE :
Only for MT 932 Série A
When completely retracting the telescopes, insistently operate the control so as
to allow all the telescopes to retract fully .
LEVER C : Controls the additional attachment.
BUTTON D : Enables transmission cut-off to channel all power from the I.C. engine to
hydraulic movements (See chapter : 37 - USE OF TRANSMISSION CUT-
OFF in paragraph : 2 - DESCRIPTION).
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
LEVER A : Controls the lifting of the load and the tilt of the carriage.
- The lever backwards when lifting.
- The lever forwards when lowering.
- The lever to the left for reverse tilt.
- The lever to the right for forward tilt.
BUTTON B : Controls telescope extend.
BUTTON C : Controls telescope retract.
BUTTON D - E : Controls the additional attachment.
BUTTON F : Enables transmission cut-off to channel all power from the I.C. engine to
hydraulic movements (See chapter : 37 - USE OF TRANSMISSION CUT-
OFF in paragraph : 2 - DESCRIPTION).
BUTTON G : OPTION Jib head electrovalve.
A
D
B
E
C
G
F
C
B
A
