Manitou E-E3 Series User Manual

2-61
13 - LIFTING RING ON SINGLE CARRIAGE
CONDITIONS OF USE
Follow the instructions given in the instruction manual (see: 1 - OPERATING
AND SAFETY INSTRUCTIONS: INSTRUCTIONS FOR HANDLING LOADS).
- The lifting ring must be used WITHOUT FORKS AND ATTACHMENTS,
but the angle of inclination of the carriage must be same as when
the forks are used in the horizontal position.
- Check the maximum permitted angle, which is 45°.
- Do not change the angle of the carriage while using the lifting ring.
- The lifting hook, the chains and slings shall have a minimum capacity
of 3000 kg with a factor of safety against breakage of 4.
LOAD CHARTS AND FUNCTION SHEETS
MT 732 Série E-E3
The load charts are given for use without forks and
without attachments.
LOAD CHARTS AND FUNCTION SHEETS
MT 932 Série E-E3
The load charts are given for use without forks and
without attachments.
N°265284
Kg
Kg Kg
Kg
Kg Kg Kg
Kg Kg Kg
Kg Kg
Kg
3000KG
MAXI
3,41 2,60 1,85
0,702,153,20
43210m
40°
30°
0m
1
2
3
4
5
5,55
6
0 KG
1400 KG
1500 KG
2000 KG
2000 KG
3000 KG
7
0°
-3°
20°
45° 63°
N°267424
MT732 + TS AS 3T
36km/h Maxi
(10m/s)
N°267425
45°
Maxi
1,44km/h (0,4m/s)
Maxi
3000KG
MAXI
0,3m Maxi
3mMini
1,50mMaxi
MT 732 + TS AS 3T
3000KG
MAXI
0KG
500KG
2500KG
6.87
0m1234567
0m
-1
1
2
3
4
5
6
7
8
9
10
45° 55° 62.4°
10°
0°
20°
30°
40°
-3.7°
N°267861
1500KG
1200KG
1000KG
2000KG
800KG
600KG
3000KG
MT932 + TS AS 3T
5.70 4.25 3.30 1.98 0.58
5.78 4.70 3.70 2.65 1.80
36km/h Maxi
(10m/s)
N°267862
45°
Maxi
1,44km/h (0,4m/s)
Maxi
3000KG
MAXI
0,3m Maxi
3mMini
1,50mMaxi
MT 932 + TS AS 3T
647083 EN (21/06/2011)
