Manitou E-E3 Series User Manual

2-62
LOAD CHARTS AND FUNCTION SHEETS
MT 1030 S Turbo Série 5-E3
The load charts are given for use without forks and without attachments.
14 - ANGULAR SECTOR ON JIB
The angular sector displays the jib angle, and thus improves the reading of the load charts.
30°
40°
45°
20°
10°
-4.1°
0°
10
9
8
1
2
3
4
5
6
7
0
-1
7.54
N°266913
6.45 6.10 5.50 4.60 3.90 3.70 2.95 2.40 2.00 1.60 0.80
12345670m
800KG
0KG
200KG
2000KG
2500KG
400KG
600KG
100KG
1200KG
1500KG
0KG
MT1030S + TS AS 3T
10
9
8
1
2
3
4
5
6
7
0
-1
9.86
N°266914
MT1030S + TS AS 3T
30°
40°
50°
60°
65.4°
20°
10°
0.4°
6.36 5.65 5.05 4.40 3.90 0.73
12345670m
900KG
2000KG
2500KG
1200KG
1500KG
0KG
MT1030S + TS AS 3T
N°266915
36km/h Maxi
(10m/s)
1,44km/h (0,4m/s)
Maxi
45°
Maxi
0,3m Maxi
3mMini
1,1m Maxi
2500KG
MAXI
647083 EN (21/06/2011)
