Manitou F-E3 Series User Manual

2-19
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen 1 km/h 5,3
2 km/h 8,6
3 km/h 18,2
4 km/h 32,5
Rear unladen 1 km/h 5,3
2 km/h 8,6
3 km/h 18,2
4 km/h 32,5
Standard attachment PFB
Weight of attachment (without fork) kg 95
Weight of forks (each one) kg 72,5
Rated capacity with standard attachment kg 3100
Tipping load at maximum reach on tyres kg 1420
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 6900
Lift truck weight without attachment kg 7070
Lift truck weight with standard attachment
Unladen kg 7310
At rated load kg 10410
Weight per axle with standard attachment (transport position)
Front unladen kg 3465
Rear unladen kg 3845
Front rated load kg 9190
Rear rated load kg 1220
Weight per axle with standard attachment (boom extended)
Front rated load kg 7580
Rear rated load kg 730
Authorised gross vehicle weight daN 28000
Contact pressure on the ground for the whole surface of each
stabilizer at maximum load when tilting
kg/cm2 -
Drag strain on the coupling hook
Unladen (sliding) daN 6100
At rated load (transmission setting) daN 8360
Pull strain with open carrier
(according to standard ISO 8313) daN 5650
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (boom retracted)
Unladen lifting s - m/mn 6,7 - 40,2
Laden lifting s - m/mn 8,7 - 31,0
Unladen lowering s - m/mn 5,7 - 47,2
Laden lowering s - m/mn 5,6 - 48,1
Telescoping motions (boom raised)
Unladen extending s - m/mn 6,4 - 24,2
Laden extending s - m/mn 6,7 - 25,3
Unladen retracting s - m/mn 7,1 - 22,8
Laden retracting s - m/mn 7,3 - 22,2
Tilting movements
Unladen digging s - °/s 3,0 - 48,8
Forward tilting unladen s - °/s 2,6 - 56,3
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear pump with flow divider
1st casing 2nd casing
Capacity cm3 22 22
Max. rating capacity unladen l/mn 53 53
Flow rate at 1600 rpm l/mn 35 35
Filtration
Return μm 15 15
Suction μm 125 125
Maximum service pressure bar 260
Telescoping circuit bar 190 / 260
Lifting circuit bar 260 / 260
Tilt circuit bar 190 / 260
Attachment circuit bar 260
Steering circuit bar 140
