Manitou F-E3 Series User Manual

2-33
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (boom retracted)
Unladen lifting s - m/mn 7,0 - 40,1
Laden lifting s - m/mn 7,3 - 38,5
Unladen lowering s - m/mn 5,2 - 54,0
Laden lowering s - m/mn 5,3 - 53,0
Telescoping motions (boom raised)
Unladen extending s - m/mn 15,7 - 21,6
Laden extending s - m/mn 15,8 - 21,8
Unladen retracting s - m/mn 10,6 - 32,3
Laden retracting s - m/mn 11,5 - 29,7
Tilting movements
Unladen digging s - °/s 3,0 - 41,9
Forward tilting unladen s - °/s 2,7 - 46,5
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen 1 km/h 5,3
2 km/h 8,6
3 km/h 18,2
4 km/h 32,5
Rear unladen 1 km/h 5,3
2 km/h 8,6
3 km/h 18,2
4 km/h 32,5
Standard attachment PFB
Weight of attachment (without fork) kg 95
Weight of forks (each one) kg 72,5
Rated capacity with standard attachment kg 3500
Tipping load at maximum reach on tyres kg 780
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 9600
Lift truck weight without attachment kg 8135
Lift truck weight with standard attachment
Unladen kg 8375
At rated load kg 11875
Weight per axle with standard attachment (transport position)
Front unladen kg 3580
Rear unladen kg 4795
Front rated load kg 9735
Rear rated load kg 2140
Weight per axle with standard attachment (boom extended)
Front rated load kg 8070
Rear rated load kg 855
Authorised gross vehicle weight daN 28000
Contact pressure on the ground for the whole surface of each
stabilizer at maximum load when tilting
kg/cm2 -
Drag strain on the coupling hook
Unladen (sliding) daN 6060
At rated load (transmission setting) daN 9380
Pull strain with open carrier
(according to standard ISO 8313) daN 6000
HYDRAULIC CIRCUIT
Hydraulic pump
Type Variable volume pistons
1st casing
Capacity cm3 45
Max. rating capacity unladen l/mn 108
Flow rate at 1600 rpm l/mn 72
Filtration
Return μm 15
Suction μm 125
Maximum service pressure bar 270
Telescoping circuit bar 200 / 270
Lifting circuit bar 270 / 270
Tilt circuit bar 190 / 270
Tilting corrector circuit bar 270
Attachment circuit bar 270
Steering circuit bar 140
