3 - 18
B8 - WINDSCREEN WASHER LIQUID LEVEL
CHECK
- Loosen screw 1 (Fig. B8/1) and remove the access panel for braking oil tank and
windscreen washer tank 2 (Fig. B8/1).
- Check visually the level.
- If necessary add windscreen washer liquid (See chapter : LUBRICANTS AND FUEL in
paragraph : 3 - MAINTENANCE) by filler port 3 (Fig. B8/2).
B9 - CAB DOOR
GREASE
Clean and lubricate the points 1 (4 lubricators) (Fig. B9) with grease (See chapter :
LUBRICANTS AND FUEL in paragraph : 3 - MAINTENANCE) and remove the surplus
of grease.
B10 - CAB VENTILATION FILTER (OPTION AIR CONDITIONING)
CLEAN
- Lift up protective casing 1 (Fig. B10).
- Lift out cabin ventilation filter 2 (Fig. B10).
- Clean the filter with a compressed air jet.
- Check its condition and change if necessary (See chapter : FILTERS CARTRIDGES
AND BELTS in paragraph : 3 - MAINTENANCE).
- Refit the filter and protective casing.
B9
1
1
B10
1
2
B8/1
1
2
B8/2
3
