3 - 30
A B
H4/3
H4/1
H4/2
TOWING THE LIFT TRUCK
Do not tow the lift truck at a speed exceeding 24 km/h.
- Put the forward/ reverser lever in neutral.
- Untighten the hand brake.
- Turn up the warning lights (OPTION).
- As the steering booster is lacking, operate slowly and energetically the steering wheel. Avoid abrupt movements and
jerks.
H4 - SLING THE LIFT TRUCK
- Take into account the position of the lift truck gravity center for lifting (Fig. H4/1).
- Place the hooks in the fastening points provided (Fig. H4/2 and H4/3).
A = 921 mm B = 879 mm (MSI 20 D + BUGGIE)
A = 999 mm B = 801 mm (MSI 25 D + BUGGIE)
A = 1084 mm B = 716 mm (MSI 30 D + BUGGIE)
