G3 - LIFT TRUCK
TOW
Do not tow the lift truck at more than 25 km/h.
- Put the forward/reverse lever and the gear shift in neutral (as model of lift truck).
- Release the parking brake.
- Put the warning lights on.
- If the I.C. engine is not running there will be no steering or braking assistance. Operate the steering and pedal slowly avoiding
sudden jerky movements.
G4 - LIFT TRUCK
SLING
MT 732 Série C-E2
MT 732 Turbo Série C-E2
MT 932 Série C-E2
MT 932 Turbo Série C-E2
- Take into account the position of the lift truck gravity center for
lifting (fig. G4/1).
A = 1480 mm B = 1080 mm MT 732 Série C-E2
A = 1480 mm B = 1080 mm MT 732 Turbo Série C-E2
A = 1465 mm B = 1095 mm MT 932 Série C-E2
A = 1480 mm B = 1080 mm MT 932 Turbo Série C-E2
- Place the hooks in the fastening points provided (fig. G4/2 and
G4/3).
3 - 39
G4/3
G4/2
