Manitou MT 928 - Page 84

2 - 40
14 - N/A
15 - N/A
16 - PREARRANGED TRAILER LOCKING
MT 732 Série C-E2
MT 732 Turbo Série C-E2
MT 932 Série C-E2
MT 932 Turbo Série C-E2
MT 1030 S Série 3-E2
MT 1030 S Turbo Série 3-E2
Enables the hydraulic connection of a braked trailer (see: 2 - DESCRIPTION: TOWING PIN
AND HOOK).
17 - CLEANFIX SELF-CLEANING FAN
MT 732 Série C-E2
MT 732 Turbo Série C-E2
MT 932 Série C-E2
MT 932 Turbo Série C-E2
MT 1030 S Série 3-E2
MT 1030 S Turbo Série 3-E2
This system, operated by switch 1, cleans the radiator core and the grille of the engine
cover by reversing the air flow.
When in use, beware of the risk of projection into the eyes.
Position A: The indicator light is on, the fan operates in self-cleaning mode for a
few seconds once every 3 minutes.
Position B: The indicator light is off, the fan is in normal operating mode.
1
B
A
