Luffing Jib Raising Procedure
Luffing Jib No. 135 on Boom No. 76
Boom and luffing jib combinations in following tables require layout jack-knifing to a specified boom-to-luffing jib
angle for raising and lowering.
WITH OR WITHOUT BOOM CATWALKS
14000 SERIES 1
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
85.3 26,0
—
— — 160.0 - 170.0 48,8 - 51,8 90
95.1 29,0 — — — 140.0 - 170.0 42,7 - 51,8 90
105.0 32,0 160.0 - 170.0 48,8 - 51,8 90 120.0 - 170.0 36,6 - 51,8 90
114.8 35,0 130.0 - 170.0 39,6 - 51,8 90 90.0 - 170.0 27,4 - 51,8 90
124.7 38,0 100.0 - 170.0 30,5 - 51,8 90 70.0 - 170.0 21,3 - 51,8 90
134.5 41,0 80.0 - 170.0 24,4 - 51,8 90 70.0 - 150.0 (c) 21,3 - 45,7 60
144.4 44,0 70.0 - 150.0 21,3 - 45,7 90 — — —
160.0 - 170.0
48,8 - 51,8 60 — — —
(a) 154.2 47,0 70.0 - 170.0 21,3 - 51,8 60 — — —
(b)(c) 164.0 50,0 70.0 - 110.0 21,3 - 33,5 60 — — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
(a) Requires lower boom point to be removed.
(b) Requires lower boom point and wire rope guide assembly No. 177364 to be removed.
(c) When equipped with boom catwalks, lowerworks jacking cylinders must be attached to 164.0 ft boom or
150.0 ft luffing jib on 134.5 ft boom over side of crawlers.
WITH OR WITHOUT BOOM CATWALKS
14000 SERIES 2 and SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
114.8 35,0 — — — 170.0 51,8 90
124.7 38,0 — — — 140.0 - 170.0 42,7 - 51,8 90
134.5 41,0 160.0 - 170.0 48,8 - 51,8 90
120.0 - 170.0 36,6 - 51,8
90
144.4 44,0 150.0 - 170.0 45,7 - 51,8 90 100.0 - 170.0 30,5 - 51,8 90
154.2 47,0 120.0 - 170.0 36,6 - 51,8 90 70.0 - 170.0 21,3 - 51,8 90
164.0 50,0 100.0 - 170.0 30,0 - 51,8 90 70.0 - 170.0 21,3 - 51,8 60
173.9 53,0 70.0 - 170.0 21,3 - 51,8 90 —
—
—
183.7 56,0 70.0 - 170.0 21,3 - 51,8 60 —
—
—
(a)(b) 193.6 59,0 70.0 - 170.0 21,3 - 51,8 60 —
—
—
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
(a) Requires lower boom point to be removed.
(b) When equipped with boom catwalks, this boom length requires wire rope guide assembly No. 177364 to be
removed and lowerworks jacking cylinders must be attached.
