8799-A, 2016-06-03
Manitowoc Cranes, Inc.
6/6
Manitowoc, Wisconsin 54220 U.S.A.
14000
Luffing Jib Raising Procedure
Luffing Jib No. 135 on Boom No. 76
WITH OR WITHOUT BOOM CATWALKS
14000 SERIES 2 and SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted
Using Fold Under Jack-Knife Method
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
95.1 29,0
70.0
21,3 70.0 21,3
105.0 32,0 70.0 - 80.0 21,3 - 24,4 70.0 - 80.0 21,3 - 24,4
114.8 35,0 70.0 - 90.0 21,3 - 27,4 70.0 - 90.0 21,3 - 27,4
124.7 38,0 70.0 - 100.0 21,3 - 30,5 70.0 - 100.0 21,3 - 30,5
134.5 41,0 70.0 - 110.0 21,3 - 33,5 70.0 - 110.0 21,3 - 33,5
144.4
154.2
44,0 70.0 - 120.0 21,3 - 36,6 70.0 - 120.0 21,3 - 36,6
47,0 70.0 - 130.0 21,3 - 39,6 70.0 - 130.0 21,3 - 39,6
164.0 50,0 70.0 - 140.0 21,3 - 42,7 70.0 - 140.0 21,3 - 42,7
173.9 53,0 70.0 - 150.0 21,3 - 45,7
——
183.7 56,0 70.0 - 160.0 21,3 - 48,8
——
(a)(b)193.6 59,0 70.0 - 170.0 21,3 - 51,8 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
(a) Requires lower boom point to be removed.
(b) When equipped with boom catwalks this boom length cannot be raised using
Fold Under Jack-Knife method.
