Part Number: 000015431 Rev01 5/19 67
Single & Twin Evaporator QuietQube® Models
Energized Parts Chart
Ice Making
Sequence of
Operation
Water
Pump
Harvest
Valve(s)
Air
Pumps
Water Inlet
Valve
Water
Dump
Valve
Liquid Line
Solenoid
Valve
Contactor
Refrigeration
Compressor &
Condenser Fan
Motor*
Length of
Time
6. Harvest Off On On Off Off On On
Bin switch
activation
Water Assist
Starts 3.5 minutes in
harvest cycle
Off ** On On On Off** On On
Until curtain switch
activation
7. Automatic
Shut-Off
Off Off Off Off Off Off Off
Until 10 min. delay
expires & all bin
switches re-close
* The condenser fan motor is controlled by a fan cycle control and may cycle on/off.
* The contactor is controlled by a low pressure control and may cycle on/off whenever power is supplied to the condensing unit.
** Water Pump On after 4 minutes - Dump Valve On after 6.5 minutes.
