Electrical Requirements
Local or state electrical code, length of wire run or materials used, can increase the minimum wire or breaker size
requirement. A qualified electrician must determine the wire and breaker size, although the minimum wire size must
meet or exceed the specifications in these charts. Refer to the condensing unit serial plate to verify electrical data.
ICVD CONDENSING UNITS
Important
Due to continuous improvements, this information is
for reference only. Please refer to the condensing
unit serial number tag to verify electrical data. Serial
tag information overrides information listed on this
page.
! Warning
ICVD2095/ICVD2096 ONLY
Connect power supply wiring directly to L1 & L2 on
the contactor. Torque screws to the torque value
specification on the contactor label. Follow all local,
state and national electrical codes.
Condensing Unit Voltage/Phase/Cycle
Maximum Fuse/
Circuit Breaker
Minimum Circuit
Amps
Minimum Wire Size Required
by Manitowoc
ICVD0695
208-230/1/60 15 amp 11.0 #12 Solid Copper Conductor
208-230/3/60 15 amp 7.5 #12 Solid Copper Conductor
230/1/50 15 amp 11.0 #12 Solid Copper Conductor
ICVD0696
208-230/1/60 15 amp 11.6 #12 Solid Copper Conductor
208-230/3/60 15 amp 10.2 #12 Solid Copper Conductor
230/1/50 15 amp 10.2 #12 Solid Copper Conductor
ICVD0895
208-230/1/60 20 amp 11.8 #10 Solid Copper Conductor
208-230/3/60 15 amp 9.1 #12 Solid Copper Conductor
230/1/50 20 amp 11.8 #10 Solid Copper Conductor
ICVD0896
208-230/1/60 20 amp 11.8 #10 Solid Copper Conductor
208-230/3/60 15 amp 9.1 #12 Solid Copper Conductor
230/1/50 20* amp 11.8 #10 Solid Copper Conductor
ICVD0996
208-230/1/60 20 amp 12.5 #10 Solid Copper Conductor
208-230/3/60 15 amp 9.5 #12 Solid Copper Conductor
230/1/50 20 amp 12.5 #10 Solid Copper Conductor
ICVD1095
208-230/1/60 20 amp 15.0 #10 Solid Copper Conductor
208-230/3/60 15 amp 15.0 #12 Solid Copper Conductor
230/1/50 20 amp 15.0 #10 Solid Copper Conductor
ICVD1096
208-230/1/60 20* amp 15.0* #10 Solid Copper Conductor
208-230/3/60 15* amp 15.0* #12 Solid Copper Conductor
230/1/50 20* amp 15.0* #10 Solid Copper Conductor
ICVD1195
208-230/1/60 25 amp 14.5 #8 Solid Copper Conductor
208-230/3/60 15 amp 9.3 #10 Solid Copper Conductor
230/1/50 35 amp 15.7* #8 Solid Copper Conductor
ICVD1195
Bristol
Compressor
208-230/1/60 25 amp 14.2 #8 Solid Copper Conductor
208-230/3/60 15 amp 9.5 #10 Solid Copper Conductor
230/1/50 35 amp 15.7* #8 Solid Copper Conductor
ICVD1196
208-230/1/60 35* amp 25.0* #8 Solid Copper Conductor
208-230/3/60 25* amp 20.0* #10 Solid Copper Conductor
230/1/50 35* amp 25.0* #8 Solid Copper Conductor
ICVD1495
208-230/1/60
20 amp
15 amp
20amp
20.0
15.0
20.0
#10 Solid Copper Conductor
#12 Solid Copper Conductor
#8 Solid Copper Conductor
208-230/3/60
230/1/50
