Manitowoc ID0682C User Manual

Section 2 Installation
Part Number 000007924 5/14 15
QUIETQUBE
®
ICE MACHINE HEAD SECTION
ICVD1496
208-230/1/60
20 amp
15 amp
20 amp
11.7
8.9
11.7*
#10 Solid Copper Conductor
#12 Solid Copper Conductor
#8 Solid Copper Conductor
208-230/3/60
230/1/50
ICVD1895
208-230/1/60
40 amp
25 amp
40 amp
25.0
20.0
25.0
#8 Solid Copper Conductor
#10 Solid Copper Conductor
#8 Solid Copper Conductor
208-230/3/60
230/1/50
ICVD1896
208-230/1/60
40* amp
25* amp
30* amp
25.0*
20.0*
20.0*
#8 Solid Copper Conductor
#10 Solid Copper Conductor
#8 Solid Copper Conductor
208-230/3/60
230/1/50
ICVD2095**
208-230/1/60
208-230/3/60
40 amp
20 amp
30.0
20.0
#6 Solid Copper Conductor
#10 Solid Copper Conductor
ICVD2096**
208-230/1/60
208-230/3/60
50 amp
30 amp
40.0
30.0
#6 Solid Copper Conductor
#10 Solid Copper Conductor
* Indicates preliminary data - Subject to change
**ICVD2095 Only - Verify the direction of the rotation is correct on the 3ph scroll compressor. The ice machine will have high suction pressure,
low discharge pressure and will be noticeably loud. Reverse two incoming power leads to reverse rotation.
Ice Machine
Voltage
Phase
Cycle
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit
Amps
Total
Circuit
Amps
**Minimum Wire Size
Required by Manitowoc
Minimum Breaker
Size Required by
Manitowoc
I0600C - I0686C
115/1/60
230/1/50
15 amp
15 amp
1.1
1.5
N/A
#14 Solid Copper
Conductor
15 amp
15 amp
I0870C - I0876C
115/1/60
230/1/50
15 amp
15 amp
1.1
1.5
N/A
#14 Solid Copper
Conductor
15 amp
15 amp
I0970C
115/1/60
230/1/50
15 amp
15 amp
1.1
1.5
N/A
#14 Solid Copper
Conductor
15 amp
15 amp
IB0600C
IB0870C - IB0876C
IB1070C - IB1076C
115/1/60
230/1/50
15 amp
15 amp
N/A
1.1
1.5
#14 Solid Copper
Conductor
15 amp
15 amp
I1070C - I1076C
I1176C
115/1/60
230/1/50
15 amp
15 amp
1.1
1.5
N/A
#14 Solid Copper
Conductor
15 amp
15 amp
I1470C - I1476C
I1870C - I1876C
I2170C - I2176C
115/1/60
208-230/1/60
230/1/50
15 amp
15 amp
15 amp
1.1
0.8
1.5
N/A
#14 Solid Copper
Conductor
15 amp
15 amp
15 amp
** All conductors must be solid copper wire
